Authentication in ASP.NET MVC With Example

Authentication in ASP.NET MVC allows you to identify and verify users before granting access to protected parts of the application. Here's a high-level overview of how authentication works in ASP.NET MVC (non-Core) and how to implement it.

---

✅ Types of Authentication in ASP.NET MVC

1. Forms Authentication (Traditional)
2. Windows Authentication
3. OAuth / External Login (Google, Facebook, etc.)
4. Token-Based Authentication (JWT, often with Web API)

For most web apps, Forms Authentication is commonly used.

---

🔐 1. Forms Authentication (with Login Page)

✅ Steps:

1. Enable Forms Authentication in Web.config:

<configuration>
  <system.web>
    <authentication mode="Forms">
      <forms loginUrl="~/Account/Login" timeout="30" />
    </authentication>
    <authorization>
      <deny users="?" /> <!-- Deny anonymous users -->
    </authorization>
  </system.web>
</configuration>

2. Create Login View + Controller Logic:

Model:

public class LoginViewModel
{
    public string Username { get; set; }
    public string Password { get; set; }
}

Controller:

public class AccountController : Controller
{
    public ActionResult Login() => View();

    [HttpPost]
    public ActionResult Login(LoginViewModel model)
    {
        if (IsValidUser(model.Username, model.Password))
        {
            FormsAuthentication.SetAuthCookie(model.Username, false);
            return RedirectToAction("Index", "Home");
        }
        ModelState.AddModelError("", "Invalid login attempt.");
        return View(model);
    }

    public ActionResult Logout()
    {
        FormsAuthentication.SignOut();
        return RedirectToAction("Login", "Account");
    }

    private bool IsValidUser(string username, string password)
    {
        // Replace with DB check or identity logic
        return username == "admin" && password == "1234";
    }
}

View (Login.cshtml):

@model YourApp.Models.LoginViewModel

@using (Html.BeginForm()) {
    <label>Username</label>
    @Html.TextBoxFor(m => m.Username)

    <label>Password</label>
    @Html.PasswordFor(m => m.Password)

    <button type="submit">Login</button>
}

---

🔐 2. Protecting Actions with [Authorize]

Use this to restrict access:

[Authorize]
public ActionResult SecurePage()
{
    return View();
}

To allow anonymous access:

[AllowAnonymous]
public ActionResult Login() => View();

---

🔄 Redirect on Session Expiry

ASP.NET will automatically redirect to the login page if the user is not authenticated, based on the loginUrl in Web.config.

---

🔑 Alternative: ASP.NET Identity (for more advanced use)

If you're using ASP.NET Identity (like with Visual Studio templates), authentication becomes more powerful with roles, claims, password recovery, etc.

---

✅ Goal: Authentication in ASP.NET MVC using Forms Authentication + SQL Server

🧱 Structure Overview

• ✅ SQL Server with Users table
• ✅ ASP.NET MVC Login screen
• ✅ Authenticate and store the cookie using FormsAuthentication
• ✅ Restrict access using [Authorize]

---

🗃️ 1. SQL Server Table (Users)

CREATE TABLE Users (
    Id INT PRIMARY KEY IDENTITY,
    Username NVARCHAR(100) NOT NULL,
    Password NVARCHAR(100) NOT NULL
);

Add a test user:

INSERT INTO Users (Username, Password)
VALUES ('admin', '1234'); -- store hashed passwords in production!

---

🔌 2. Set Up Your MVC Project

1. Create an ASP.NET MVC Project (Visual Studio → New Project → ASP.NET MVC).
2. Add an ADO.NET Entity Data Model to connect to your Users table.

---

🧑‍💻 3. Create Login Model

public class LoginViewModel
{
    [Required]
    public string Username { get; set; }

    [Required]
    [DataType(DataType.Password)]
    public string Password { get; set; }
}

---

🎮 4. Create Account Controller

public class AccountController : Controller
{
    private YourDbContext db = new YourDbContext(); // Replace with your EF context

    public ActionResult Login() => View();

    [HttpPost]
    public ActionResult Login(LoginViewModel model)
    {
        if (ModelState.IsValid)
        {
            var user = db.Users.FirstOrDefault(u => u.Username == model.Username && u.Password == model.Password);

            if (user != null)
            {
                FormsAuthentication.SetAuthCookie(user.Username, false);
                return RedirectToAction("Index", "Home");
            }

            ModelState.AddModelError("", "Invalid username or password.");
        }

        return View(model);
    }

    public ActionResult Logout()
    {
        FormsAuthentication.SignOut();
        return RedirectToAction("Login", "Account");
    }
}

---

🧾 5. View (Login.cshtml)

@model YourNamespace.Models.LoginViewModel

@using (Html.BeginForm()) {
    @Html.LabelFor(m => m.Username)
    @Html.TextBoxFor(m => m.Username)
    @Html.ValidationMessageFor(m => m.Username)

    @Html.LabelFor(m => m.Password)
    @Html.PasswordFor(m => m.Password)
    @Html.ValidationMessageFor(m => m.Password)

    <button type="submit">Login</button>
}

---

🔐 6. Protect Pages Using [Authorize]

[Authorize]
public class HomeController : Controller
{
    public ActionResult Index()
    {
        return View();
    }
}

---

⚙️ 7. Web.config Configuration

<system.web>
  <authentication mode="Forms">
    <forms loginUrl="~/Account/Login" timeout="30" />
  </authentication>
  <authorization>
    <deny users="?" />
  </authorization>
</system.web>

---

✅ 8. Done! Now:

• Visit any secure page → redirected to Login
• Enter correct credentials from DB → redirected to Home
• Click Logout → session removed

---

🔒 Security Note

• In real applications, store passwords as hashes (e.g., SHA256 or bcrypt).
• You can use ASP.NET Identity for more secure systems with role management, password hashing, and email verification.

⚠️ Without Authentication

• Anyone can change your data
• No audit trail of who did what
• Can’t protect sensitive features
• Security threats (unauthorized access, data leaks)
